Damping torque 2 Nm to 11 Nm
Damping direction right
Construction size Ø 47 to 70 mm
Rotational speed max. 50 rpm
Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80 % of their original damping moment. The service life may be significantly higher or lower, depending on the application.
Operating temperature range -10 °C to +50 °C
Material Outer body: Steel
Mounting In any position
Information to the shaft FDN-47: Ø 6 +0 / -0.03
Turn the shaft in the opposite direction to the brake direction to avoid damaging the freewheel mount. No axial or radial forces may be induced via the shaft.
Do not use rotary dampers as supports. Provide an external guide or support.
Special designs available on request.
